Product Features
- 7-inch capacitive touchscreen display: 800 × 480 resolution LCD offering clear visuals and an easy-to-use interface
- Third-party integrations: Supports seamless integration with third-party solutions to extend functionality
- Multiple connectivity options: Supports up to 8 additional monitors, 8 alarm sensors, and 8 IP cameras
Specifications
| Category | Specification |
| Display | 7″ TFT LCD, capacitive touchscreen |
| Screen Resolution | 800 × 480 |
| Built-in Camera | No |
| Power Supply | PoE and +12 V DC (PSU not included) |
| Power Consumption | 6 W (standby: 2.5 W) |
| Dimensions | 195 × 127 × 27 mm |
| Available Colours | Black, White |
| Body Material | Plastic |
| Installation Type | Wall mount |
| Mounting Options | Horizontal and vertical |
| Network Connection | Ethernet (8P8C) |
| Individual Panels Supported | Up to 9 panels |
| Multi-apartment Panels Supported | Up to 9 panels |
| Additional Monitors | Up to 8 monitors |
| Additional Connectors | SD card slot (SDHC) |
| Memory Function | Stores up to 64 photos in internal memory |
| Interface | Multi-language graphical and WEB interface |
| Number of IP Cameras | Up to 8 cameras |
| Intercom Type | Audio intercom (no built-in camera) |
| Message Reception | Yes |
| Standby Screensaver | Single IP camera live view |
| Do Not Disturb | Yes, time-customisable |
| Silent Mode | Yes, time-customisable |
| Software Update | Via WEB interface Via BAS-IP update server |
