Product Features
- Size: 255Lx49Wx28H(mm)
- Holding Force: 280kg(600Lbs)
- Input Voltage: DC12V or DC24V
- Current: 12V/500mA±10%; 24V/250mA±10%
- LED: Red shows locked; Green shows unlocked
- Signal Output: Lock signal (NO/NC/COM)
- Suitable for: Wooden door, Glass door, Metal door, Fireproof door
- Operating Temp: -10-+55 °C(14-131F)
- Weight: 2.1kg
