Specifications
| Category | Specification |
| Interface for BAS-IP Panels | RS485 (A & B) |
| Power Supply | +12 V DC; powered by BAS-IP panels |
| Current Consumption | 0.15 A |
| External Reader Interface | Wiegand 26, 34, 58, 64, 66 bit |
| Access Controller Interface | Wiegand 26, 34, 58, 64, 66 bit |
| Operating Temperature | -40 – +70 °C |
| Storage Temperature | -15 – +65 °C |
| Permissible Humidity | 20 – 80% |
| Degree of Protection | IP30C |
| Weight | 0.11 kg |
| Dimensions (without mounting brackets) | 82 × 56 × 34 mm |
| Dimensions (with mounting brackets) | 115 × 56 × 34 mm |
| Additional Features | Power output for connected external readers with +12 V DC Alternative power output for external readers with +5 V DC Activity and data transmission intensity indicator LED |
