TR – D2153IR6 2.7 – 13.5

TRASSIR TR-D2153IR6 (2.7-13.5mm) is a 5MP (2592×1944) IP outdoor camera that can work all year round in tough conditions. It is made of strong metal housing with IP67 dust/moisture resistance and an IK08 shock protection rating. It operates within an impressive temperature range of -40°C to +60°C. The camera is equipped with TVS 4000V lightning protection and will continue recording even in the most severe weather conditions. With an F/1.8 aperture, the horizontal viewing angle from 98° to 38° and vertical from 73° to 30°, a varifocal lens of 2.7-13.5mm lets you capture high-quality images on tape or drive disk storage media. The device can be connected via an RJ-45 network port, supports up to 128GB microSD card recording, and has power input that accepts both PoE or DC12V with a maximum consumption of 7.2W only. Its size is only about 234.2×77.3×77 mm, and it weighs around 635g, making it very compact yet capable of performing enterprise-level surveillance tasks for different types of businesses during working hours when needed.

Product Feature

  • Software detection of movement and people.
  • Detection of crossing the virtual line.
  • Control of the area.
  • IR illumination with a range of 60 m.
  • WDR 120 dB – minimizes the effect of different contrast lighting on image quality.
  • 3D DNR – spatial noise reduction.
  • Support for shooting in vertical resolution (corridor mode) with an aspect ratio of 9:16.
  • Defog – Increases the contrast to eliminate the effect of fog or smoke in the scene.
  • ROI – the function of freezing on the selected area and simultaneously reducing the resolution in small parts of the frame to optimize the bitrate.
  • BLC – Backlight Compensation.
  • HLC – local exposure masking.
  • Day/Night mode with ICR, with sufficient illumination blocking IR rays (in the dark it is shifted to increase the sensitivity of the matrix and the backlight).


Audio: audio in/out 1/1

WDR: WDR (120 dB)

Maximum video output resolution: 2592×1944

Image sensor: 1/2.8″ CMOS

Bitrate (Mb/sec): 8

Power supply: DC 12 V, PoE

Lens (mm): 2.7-13.5

Weight Net (kg): 0.635

Sensitivity(Lux): 0,002

Ingress protection: IP67

Dimensions (mm): 234.2×77.3×73.2

Power consumption, Watt: 7.2

Working temperature, C°: -40…+60

Day/Night Mode: Mechanic IR-filter

Network interfaces: RJ-45
