Product Features
- 4-inch LCD screen: Capacitive touchscreen for easy navigation through menus
- Built-in mixing console: Supports mixing of 5 audio channels – 1 microphone, 2 AUX ports, 1 Bluetooth channel, and 1 USB port
- Mobile app for remote management: Enables configuration of paging zones and scheduled announcements
- Remote updates: Allows updating the console with the latest security patches and features
- Zone-based announcements: Supports paging across all zones, selected zones, or specific IP endpoints
Specifications
| Category | Specification |
| Power Supply | DC 12 V / 1.5 A |
| Signal-to-Noise Ratio | ≥ 80 dB |
| Audio Sampling & Bit Rate | 8 kHz – 44.1 kHz, 16 bit, 8 kbps – 320 kbps |
| Frequency Response | 100 Hz – 16 kHz |
| Network Protocol | SIP (RFC 3261), HTTP, TCP/IP, UDP, ARP, ICMP, IGMP, FTP, DHCP |
| Configuration Method | Local settings / Web page |
| Mounting Method | Desktop |
| Interface | 1 × RJ45 Ethernet port 1 × USB 2.0 2 × Line input 1 × Line output 1 × Relay input 1 × Power supply port |
| Dimensions | 144 × 144 × 34 mm |
| Weight | 0.55 kg |
| Standard Accessories | 1 × Microphone rod 1 × Terminal block connector 1 × Installation manual 1 × Certification |
| Optional Accessories | DC 12 V / 1.5 A power adapter (US / EU / UK / AU) |
| Packed Dimensions | 340 × 252 × 102 mm |
| Gross Weight | 1 kg |
