Specifications
| Category | Specification |
| Module Supply Voltage | +12 V |
| Power Consumption (Operating Mode) | 1 W |
| Standby Power Consumption | 0.06 W |
| Maximum Current of Connected Load | 7 A (per channel) |
| Maximum Constant Load Voltage | +30 V |
| Maximum AC Load Voltage | ~250 V |
| Operating Temperature | -40 – +75 °C |
| Storage Temperature | -15 – +65 °C |
| Permissible Humidity | 20 – 80% |
| Degree of Protection | IP30C |
| Overall Dimensions | 114.5 × 57.5 × 34 mm |
| Weight | 0.11 kg |
