Key features:
- Interoperable: The reader’s Wiegand output easily interfaces with most existing Wiegand protocol access control panels. Different formats are available: Wiegand 32 or 37 bits.
- Configuration is not required: The ARCS-A/BT Easyline Bluetooth reader is pre-configured. Plug & Play, no configuration is required to read Easyline RFID or mobile credentials
- Multi-technology reader: It is easy to manage extensions, upgrades and technology migrations with ARCS-A/BT Easyline
- Easy to install: The ARCS-A/BT Easyline is a RFID / Bluetooth® reader and is absolutely easy to install. It is specially designed to be installed on any type of surface without spacer, such as metal, concrete, bricks, etc. It is suitable for surface mounted wall installations and compatible with European and American flush-mounting boxes. The removable terminal block in the reader gives it great installation flexibility.
- Capability to withstand tough environments: The ARCS-A/BT Easyline can withstand harsh environments, operate outside (IP65 level) and offers a high impact resistance (IK10).
- Enhanced security: Data encryption in the ARCS-A/BT Easyline reader and mutual authentication between the card and reader offers enhances security. The reader uses the latest MIFARE® DESFire® EV2 contactless chip technologies with advanced data security mechanisms
- Secure Messaging EV2: Secure transaction method based on AES-128 that offers protection against interleaving and replay attacks.
- Proximity Check: Improved protection against relay attacks
- Equipped with security-standard encryption and sophisticated key management mechanisms, Easyline minimises the risk of duplicated card or compromised data
Specifications:
- Frequency: 13.56 MHz + Bluetooth® (Low Energy)
- Chip: STid Mobile ID® (virtual card), MIFARE® DESFire® EV2, NFC (HCE)
- Interfaces: Wiegand 32 or 37 bits
- Power supply: 7 – 28 VDC / 150 mA/12 VDC max
- Color: Black
- Operating temperatures: – 30°C to + 70°C
- Protection: IK10 certified reinforced vandal-proof structure
- Standards: ISO14443 types A & B, ISO18092 / Certifications: CE (Europe), UKCA (United Kingdom), FCC (USA), IC (Canada), BIS (India), RCM (Australia & New Zealand), UL, RoHS & UL294 Indoor & Outdoor
- Functions: Pre-configured secure read only
- Reading distances: 0 – 8 cm in RFID / 0 – 20 m in Bluetooth®
- Material: ABS-PC UL-V0 (black)
- Dimensions (h x w x d): 106,64 x 80 x 25,70 mm
- Storage temperature: -40°C to +85°C
- Resistance: IP65 level (excluding connectors) – weather, water and dust resistant (CEI NF EN 61086 certification) / Humidity: 0 – 95%
