Product Features
- Ready for home automation: Allows users to control curtains, lifts, and lights directly from the panel
- Quad view camera monitoring: Enables viewing up to four camera feeds simultaneously
- Customisable scenes: Configure how connected devices such as lights, curtains, alarms, and doorbells behave under preset conditions
Product Specifications
| Category | Specification |
| Display | 7″ IPS LCD, capacitive touchscreen |
| Operating System | Android 10.0 |
| Screen Resolution | 1024 × 600 |
| Built-in Camera | No |
| Wi-Fi | 2.4 GHz (IEEE 802.11b/g/n) |
| Power Supply | PoE and +12 V DC (PSU not included) |
| Power Consumption | 6 W (standby: 2.5 W) |
| Dimensions | 195 × 127 × 27 mm |
| Available Colours | Black, White |
| Body Material | Plastic |
| Installation Type | Wall mount |
| Mounting Options | Horizontal and vertical |
| Network Connection | Ethernet (8P8C) |
| Individual Panels Supported | Up to 9 panels |
| Multi-apartment Panels Supported | Up to 9 panels |
| Additional Monitors | Up to 8 monitors |
| Additional Connectors | SD card slot (SDHC) |
| Memory Function | Photo, video, and audio recording to SD card |
| Interface | Multi-language graphical and WEB interface |
| Number of IP Cameras | Up to 32 cameras |
| Call Ringtones | 9 selectable melodies |
| Custom MP3 Ringtones | Yes |
| Intercom Type | Audio intercom (no built-in camera) |
| Home Automation Control | Lights, curtains, lift |
| Scenes | Yes |
| Answering Machine | Yes |
| Message Reception | Yes |
| Multimedia Features | View video, photo, and audio files from SD card |
| Standby Mode | Yes, time-customisable |
| Standby Screensaver Options | Multi-camera live view (up to 4 cameras) Clock Photo frame Live tour view (up to 16 cameras, adjustable time) Single IP camera live view |
| Do Not Disturb | Yes, time-customisable |
| Silent Mode | Yes, time-customisable |
| Backup Photos During Call | Yes |
| Third-party Applications | Supported |
| Third-party Widgets | Supported |
| Software Update | Via WEB interface Via SD card Via BAS-IP update server |
