These are the Sampo S3’s short highlights; what are the main ones?
- One-stop RFID solution. External hardware is not required because of the integrated antenna and edge computing.
- With eight years of unwavering performance, the Sampo product line’s quality is undeniable.
- It is simple to mount and install in almost any place because of its lightweight and streamlined design. PoE (Power over Ethernet) and integrated mounting brackets.
Specifications of Sampo S3
You can find key specifications of Sampo S3 in the table given below:
| Supported standard
Frequency band Regulatory |
ISO 18000-63 (EPC Class 1 Gen2v2)
ETSI 865.6-867.6 MHz and FCC/IC 902-928 MHz |
| Integrated antenna features | Wide band antenna which covers ETSI and FCC/
IC frequency band, 7dBIc circular polarized, Beam width 80° |
| Radiated power (integrated antenna) | Maximum: 33 dBm (2W) ERP / 3.3 W EIRP
Minimum: 4 dBm (2.5mW) / 4 mW EIRP |
| Memory | 1GB RAM 8GB Flash |
| CPU | Quad-core A7 1.1GHz |
| Indicators | 4 pcs LEDs: Connection, Error/status, Power, RF Buzzer for sound indications |
| USB | USB host, type A USB device, type C (CDC serial port and HID profiles supported) |
| Bluetooth | BT 2.1 + EDR/3.0/4.1 LE /BT4.2 |
| Software | Ready-to-use Nordic ID NUR API that provides full control over the reader. Application can be written with modern programming languages. MQTT support (broker or client). Compatible with existing Nordic ID fixed readers. |
| Security | TLS v1.3, WLAN profiles: WPA2-Personel and WPA2- Enterprise (PEAP-MSCHAPV2 and EAP-TTLS/PAP) |
