Product Features
- 2 MP camera: Enables accurate reading of QR codes and license plates
- IP65 rating: Suitable for both indoor and outdoor installations
- Memory card support: Supports MicroSD cards up to 32 GB
- Supported access cards: Mifare® and NFC card technologies for secure identification
Specifications
| Category | Specification |
| Panel Type | Individual |
| Camera | 1/2.8″ |
| Resolution | 2 MP |
| Camera Angle | 110° (horizontal) |
| Output Video | Full HD (1920 × 1080), H.264 Main Profile |
| Wide Dynamic Range (WDR) | Yes |
| Night Backlight | 12 LEDs |
| Light Sensitivity | 0.01 Lux |
| Protection Class | IP65 |
| Impact Resistance | IK06 |
| Working Temperature | -40 °C to +65 °C |
| Power Consumption | 5.5 W (standby: 2.1 W) |
| Supported Cards | Mifare® Ultralight, Ultralight EV1, Light ID, Standard, Classic (1K/4K), Classic EV1 (1K/4K), DESFire Light (read-only UID, 4 bytes), DESFire EV1 (read-only UID, 4 bytes), NFC (ISO 14443) |
| Wi-Fi | 2.4 GHz (IEEE 802.11 n) |
| Power Supply | +12 V DC, IEEE 802.3af PoE |
| Memory Card Support | MicroSD up to 32 GB |
| Body Material | Plastic |
| Available Colours | Black, Silver |
| Panel Dimensions | 52 × 137 × 28 mm |
| Installation | Surface mounting with or without Sun & Rain cover (included) |
| Additional Accessories | Angled bracket (35°), sold separately |
