Quantum Speed Gate DS-Q70

Quantum Speed Gate DS-Q70 is a next-gen, cutting-edge speed gate model with an open and close speed rate of 0.2 seconds making it the fastest in the market and an unrivalled choice for high-traffic areas. Exuding sophistication in classic black and white, its sleek design seamlessly integrates with upscale environments. Its elite security and safety include automatic reset, infrared sensor alarms, LED indicators, and anti-intrusion functions, it epitomises uncompromising security. Crafted to accommodate wide passageways ranging from 600mm to 1100mm, it ensures seamless transit for pedestrians, wheelchair users, or heavy or large luggage. Engineered for seamless integration, the DS-Q70 effortlessly syncs with any type of access control system, like face, fingerprint, card solution, QR code, etc. offering unparalleled versatility. Moreover, its customisable option for logo, colour, and dimensions adding to its sophistication and opulence.


  • Robust durability and reliability, with high performance and minimal maintenance
  • Low noise and zero mechanical impact for a seamless experience
  • Automatic reset feature locks swing arms within 5 seconds of passenger delay, enhancing security
  • Fire safety compliance ensuring opening of swing arms during power outages
  • Selectable single or bi-directional functionality offers versatility to meet specific needs
  • LED indicators clearly communicate entry status, through red and green lights
  • Infrared sensor alarms detect and deter illegal and reverse intrusions, strengthening security
  • Anti-intrusion, anti-reverse, and anti-trailing functions fortify security by preventing unauthorized access
  • Resilient glass arms that can automatically reset after impact, for uninterrupted operation
  • Lightning-fast open and close speed of 0.2 seconds, adjustable to suit varying requirements
  • Simple installation and maintenance procedures
  • Comes with a 3-year warranty for peace of mind


  • Model No. : DS-Q70
  • Type: Speed Gate
  • Communication: Dry contact, Relay signal, RS485
  • Framework Material: Steel + White and black stoving varnish
  • Arms material: Plexiglas-transparency
  • Swipe Card panel Material: Tempered glass
  • Dimension: 1400 *120 * 978mm
  • Net Weight: 75kg/pcs
  • Passage Width: 600~1100mm
  • Arm Height: 900~1800mm
  • Passing Direction: Single directional or Bi-directional
  • Power Supply: AC220V/110V, 50/60Hz
  • MCBF: 15 million
  • Power Consumption: 20W
  • Operation Temperature: -20 °C – 75 °C
  • Operation Voltage: 24V DC
  • Operation Humidity: 0 – 95% (No freeze)
  • Working Environment: Indoor / Outdoor
  • Flow Rate: 45 people per minute
  • Emergency: Arms will open automatically
  • Flexibility: Integrate with any type of access control
  • Infrared Sensor: 6 Pairs (standard)
  • LED Indicator: Yes; red and green
  • Certification: Compliance CE, RHOS
