Product Features
- Rugged build: Aluminium alloy casting with a stainless-steel bracket and industrial-grade chips, designed to operate in temperatures from -40 °C to +70 °C
- Supports common communication protocols: SIP, ONVIF, TCP/IP, UDP, HTTP, RTP, RTSP, ARP, ICMP, NTP, DHCP, and audio signal transmission over IP
- Local storage: 80 MB built-in storage for local audio playback
- Smart CCTV integration: Automatically issues audio warnings for intruders when integrated with CCTV cameras
- High-output audio with low power consumption: Delivers up to 120 dB sound output using a 10 W amplifier and signal processor
Specifications
| Category | Specification |
| Power Source | DC 24 V, PoE (IEEE 802.3af / 802.3at) |
| Power Consumption | ≤ 3 W |
| Network Protocols | TCP/IP, UDP, HTTP, RTP, RTSP, ARP, ICMP, NTP, SIP, ONVIF, DHCP |
| Audio Codec | Opus, PCMU (G.711u), PCMA (G.711a), G.722 |
| Frequency Response | 280 Hz – 12.5 kHz |
| Power Output | 15 W (DC 24 V / PoE / PoE+) |
| Data Interface | 100BASE-TX, RJ45 connector |
| Audio Input | 1 × Line/Mic input (balanced, switchable) |
| Control Input | 2 × inputs |
| Control Output | 1 × output |
| Operating Temperature | -40 °C to +70 °C |
| Housing Material | Aluminium alloy |
| Dimensions | 222 × 162 × 281 mm |
| Weight | 1600 g |
